3612 UV Conformal Coating Coating Protection Of PCB Circuits And Components
Product Description● One-component UV conformal coating● Amber transparent liquid● Fluorescent effectProduct Features● Curing method: UV + moisture curing● Adhesion: Excellent adhesion to PCBs● Weatherability: Excellent aging resistance● Operating temperature: -65~125°C● Noticeable features: Low energy curing, excellent compatibilityDirection for useThe surface should be dry and free of grease.Recommended dry film thickness: 85~150 μm.According to the internal laboratory test data of Huitian, a UV mercury lamp is best for 3612.The recommended curing energy is as follows:Curing energy/mJ/cm2UVAUVBUVCMin1200600400Max250015001000Technical parametersReference standardItemUnitValueUV curing physical property indexes (1000W UV mercury lamp curing)Q/HTXC 4Appearance–Amber liquidGB/T2794Viscosity (25℃)mPa.s500~900GB/T13354Densityg/cm31.0~1.1Q/HTXC 4Tack-free energymJ/ cm21500GB/T 2411HardnessShore D50~65GB/T 9286Adhesion–5BGB/T 1693Dielectric constant 1 MHz–3.2GB/T 1692Volume resistivityΩ.cm＞1.0×10*14Packing SpecificationOrder code: 3612H6, 1kg/barrel, 12 barrels/cartonStorageStore at 10-26°C in a cool and dry place. Shelf life is 12 months.
